Dimensions (measurements on drawings below are in millimeters)
|
|
| Width (inches) | 35,4 |
| Depth (inches) | 29,1 |
| Height (inches) | 66,1 |
| Weight (pounds) | 4255 |
| Firebox width (inches) | 15,7 |
| Firebox depth (inches) | 14,2 |
| Bakeoven width (inches) | 17,7 |
| Bakeoven depth (inches) | 13,2 |
Heating performance |
|
| Energy class | A |
| Heated area, sq ft (depending on heating requirements) | 450-850 |
| Nominal heat output, kW | 2,9 |
| Efficiency % LHV | 80 |
| Maximum load of wood per 24 hours, lbs | 37 |
| Heat release time at 100%, in hours (this is how long the heater stays at its hottest) | 5.1 |
| Heat release time at 50%, in hours (this how long the heater stays above 50% of its hottest) | 15.7 |
| Heat release time at 25%, in hours (this how long the heater stays above 25% of its hottest; aka T25) | 24.4 |
Safety distances to combustibles |
|
| Safety distance, back, inches (can be reduced to 3" with a UL/ULC specified heat shield) | 20 |
| Safety distance, sides, inches (can be reduced to 3" with a UL/ULC specified heat shield) | 14 |
| Safety distance, top (inches) | 10 |
| Safety distance, front (inches) | 48 |
Chimney connection and combustion air information |
|
| Recommended flue diameter, inches | 7-8 |
Technical information
Height (inches)
