TU2200

Connection below

Downloadable documents

Dimensions
Width, in	40,2
Depth, in	23,6
Height, in	60,2
Weight, lbs	4057
Heat technology
Energy class	A+
Area to be heated, ft²	450-1100
Rated power (min-max), kW	2,7
Efficiency, %	87
Maximum amount of wood, lbs	28,7
Heat release time (h) 100%	4.4
Heat release time (h) 50%	17.5
Heat release time (h) 25%	26.2
Safety distances
Safety distance back, in	20
Safety distance side, in	14
Safety distance up, in	10
Safety distance front, in	48
Chimney connection and combustion air information
Recommended flue diameter, ø in	7-8

TU2200T

Top Connection

Downloadable documents

Dimensions
Width, in	40,2
Depth, in	23,6
Height, in	60,2
Weight, lbs	3938
Heat technology
Energy class	A+
Area to be heated, ft²	450-1100
Rated power (min-max), kW	2,5
Efficiency, %	83
Maximum amount of wood, lbs	28,4
Heat release time (h) 100%	4.3
Heat release time (h) 50%	14.4
Heat release time (h) 25%	25.1
Safety distances
Safety distance back, in	20
Safety distance side, in	14
Safety distance up, in	10
Safety distance front, in	48
Chimney connection and combustion air information
Recommended flue diameter, ø in	7-8
