Pyry M

News Material

Pyry M

4,5 kW Cast stone Electric heater

Heater power

4.5 kW

Sauna size

106-212 m3

News Material

Pyry M

6,8 kW Cast stone Electric heater

Heater power

6.8 kW

Sauna size

177–318 m3

News Material

Pyry M

8,5 kW Cast stone Electric heater

Heater power

8.5 kW

Sauna size

247-459 m3

News Material

Pyry M

10,2 kW Cast stone Electric heater

Heater power

10.2 kW

Sauna size

318–530 m3

Cladding

Sauna size

Technical specifications

Pyry M 45

Sauna size: 106-212 m3

Product number online store SS1658
EAN code 6417560004982
Certificate ETL

Dimensions
Heater power, kW 4.5
Diameter, in 14
Height, in 31-37
Weight without sauna stones, lb 97
Maximum stone capacity, lb 66
Adjustable feet, in 1

Materials
Heater cladding
Frame

Safety distances to combustibles
Minimum sauna size, ft3 106
Maximum sauna size, ft3 212
Safety distances to the side wall, in 2
Safety distances to the footboard in front, in 1
Safety distances to the ceiling, in 37
Safety distances to the floor, in 2

Heater control
Control unit Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase supply voltage 400V
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 3 x 10

Pyry M 68

Sauna size: 177–318 m3

Product number online store SS1659
EAN code 6417560004999
Certificate ETL

Dimensions
Heater power, kW 6.8
Diameter, in 14
Height, in 31-37
Weight without sauna stones, lb 97
Maximum stone capacity, lb 66
Adjustable feet, in 1

Materials
Heater cladding
Frame

Safety distances to combustibles
Minimum sauna size, ft3 247
Maximum sauna size, ft3 459
Safety distances to the side wall, in 2
Safety distances to the footboard in front, in 1
Safety distances to the ceiling, in 37
Safety distances to the floor, in 2

Heater control
Control unit Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase supply voltage 400V
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 3 x 10

Pyry M 85

Sauna size: 247-459 m3

Product number online store SS1660
EAN code 6417560005002
Certificate ETL

Dimensions
Heater power, kW 8.5
Diameter, in 14
Height, in 31-37
Weight without sauna stones, lb 97
Maximum stone capacity, lb 66
Adjustable feet, in 1

Materials
Heater cladding
Frame

Safety distances to combustibles
Minimum sauna size, ft3 177
Maximum sauna size, ft3 318
Safety distances to the side wall, in 2
Safety distances to the footboard in front, in 1
Safety distances to the ceiling, in 37
Safety distances to the floor, in 2

Heater control
Control unit Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase supply voltage 400V
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 3 x 16

Pyry M 102

Sauna size: 318–530 m3

Product number online store SS1661
EAN code 6417560005019
Certificate ETL

Dimensions
Heater power, kW 10.2
Diameter, in 14
Height, in 31-37
Weight without sauna stones, lb 97
Maximum stone capacity, lb 66
Adjustable feet, in 1

Materials
Heater cladding
Frame

Safety distances to combustibles
Minimum sauna size, ft3 318
Maximum sauna size, ft3 530
Safety distances to the side wall, in 2
Safety distances to the footboard in front, in 1
Safety distances to the ceiling, in 37
Safety distances to the floor, in 2

Heater control
Control unit Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase supply voltage 400V
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 3 x 16

Instructions & files

User manual Download
Cladding installation manual Download
Kiuasohjaimen käyttöohje Download
Kiuasohjaimen asennusohje Download
Kiuasohjaimen käyttöohje wifi Download
Koristekivien ladontaohje Download
