Technical specifications

Height (inches)

TU2200/50

Chimney connection base

Ladattavat dokumentit

Dimensions
Width (inches) 40.2
Depth (inches) 23.6
Height (inches) 60.2
Weight (pounds) 3800
Firebox width (inches) 15.7
Firebox depth (inches) 14.4

Heating performance
Energy class A+
Heated area, sq ft (depending on heating requirements) 450-1100
Nominal heat output, kW 2.3
Efficiency % LHV 87
Maximum load of wood per 24 hours, lbs 28.7
Heat release time at 100%, in hours (this is how long the heater stays at its hottest) 4.4
Heat release time at 50%, in hours (this how long the heater stays above 50% of its hottest) 17.5
Heat release time at 25%, in hours (this how long the heater stays above 25% of its hottest; aka T25) 26.2

Safety distances to combustibles
Safety distance, back, inches (can be reduced to 3" with a UL/ULC specified heat shield) 20
Safety distance, sides, inches (can be reduced to 3" with a UL/ULC specified heat shield) 14
Safety distance, top (inches) 10
Safety distance, front (inches) 48

Chimney connection and combustion air information
Recommended flue diameter, inches 7-8

TU2200T/50

Chimney connection base

Ladattavat dokumentit

Dimensions
Width (inches) 40.2
Depth (inches) 23.6
Height (inches) 60.2
Weight (pounds) 3800
Firebox width (inches) 15.7
Firebox depth (inches) 14.4

Heating performance
Energy class A+
Heated area, sq ft (depending on heating requirements) 450-1100
Nominal heat output, kW 2.5
Efficiency % LHV 83
Maximum load of wood per 24 hours, lbs 28.7
Heat release time at 100%, in hours (this is how long the heater stays at its hottest) 4.3
Heat release time at 50%, in hours (this how long the heater stays above 50% of its hottest) 14.4
Heat release time at 25%, in hours (this how long the heater stays above 25% of its hottest; aka T25) 25.1

Safety distances to combustibles
Safety distance, back, inches (can be reduced to 3" with a UL/ULC specified heat shield) 20
Safety distance, sides, inches (can be reduced to 3" with a UL/ULC specified heat shield) 14
Safety distance, top (inches) 10
Safety distance, front (inches) 48

Chimney connection and combustion air information
Recommended flue diameter, inches 7-8

TU2200T/50

Chimney connection base

Ladattavat dokumentit

Dimensions
Width (inches) 40.2
Depth (inches) 23.6
Height (inches) 60.2
Weight (pounds) 3800
Firebox width (inches) 15.7
Firebox depth (inches) 14.4

Heating performance
Energy class A+
Heated area, sq ft (depending on heating requirements) 450-1100
Nominal heat output, kW 2.5
Efficiency % LHV 83
Maximum load of wood per 24 hours, lbs 28.7
Heat release time at 100%, in hours (this is how long the heater stays at its hottest) 4.3
Heat release time at 50%, in hours (this how long the heater stays above 50% of its hottest) 14.4
Heat release time at 25%, in hours (this how long the heater stays above 25% of its hottest; aka T25) 25.1

Safety distances to combustibles
Safety distance, back, inches (can be reduced to 3" with a UL/ULC specified heat shield) 20
Safety distance, sides, inches (can be reduced to 3" with a UL/ULC specified heat shield) 14
Safety distance, top (inches) 10
Safety distance, front (inches) 48

Chimney connection and combustion air information
Recommended flue diameter, inches 7-8

TU2200T/50

Chimney connection base

Ladattavat dokumentit

Dimensions
Width (inches) 40.2
Depth (inches) 23.6
Height (inches) 60.2
Weight (pounds) 3800
Firebox width (inches) 15.7
Firebox depth (inches) 14.4

Heating performance
Energy class A+
Heated area, sq ft (depending on heating requirements) 450-1100
Nominal heat output, kW 2.5
Efficiency % LHV 83
Maximum load of wood per 24 hours, lbs 28.7
Heat release time at 100%, in hours (this is how long the heater stays at its hottest) 4.3
Heat release time at 50%, in hours (this how long the heater stays above 50% of its hottest) 14.4
Heat release time at 25%, in hours (this how long the heater stays above 25% of its hottest; aka T25) 25.1

Safety distances to combustibles
Safety distance, back, inches (can be reduced to 3" with a UL/ULC specified heat shield) 20
Safety distance, sides, inches (can be reduced to 3" with a UL/ULC specified heat shield) 14
Safety distance, top (inches) 10
Safety distance, front (inches) 48

Chimney connection and combustion air information
Recommended flue diameter, inches 7-8

TU2200/50

Chimney connection base

Ladattavat dokumentit

Dimensions
Width (inches) 40.2
Depth (inches) 23.6
Height (inches) 60.2
Weight (pounds) 3800
Firebox width (inches) 15.7
Firebox depth (inches) 14.4

Heating performance
Energy class A+
Heated area, sq ft (depending on heating requirements) 450-1100
Nominal heat output, kW 2.3
Efficiency % LHV 87
Maximum load of wood per 24 hours, lbs 28.7
Heat release time at 100%, in hours (this is how long the heater stays at its hottest) 4.4
Heat release time at 50%, in hours (this how long the heater stays above 50% of its hottest) 17.5
Heat release time at 25%, in hours (this how long the heater stays above 25% of its hottest; aka T25) 26.2

Safety distances to combustibles
Safety distance, back, inches (can be reduced to 3" with a UL/ULC specified heat shield) 20
Safety distance, sides, inches (can be reduced to 3" with a UL/ULC specified heat shield) 14
Safety distance, top (inches) 10
Safety distance, front (inches) 48

Chimney connection and combustion air information
Recommended flue diameter, inches 7-8

TU2200/50

Chimney connection base

Ladattavat dokumentit

Dimensions
Width (inches) 40.2
Depth (inches) 23.6
Height (inches) 60.2
Weight (pounds) 3800
Firebox width (inches) 15.7
Firebox depth (inches) 14.4

Heating performance
Energy class A+
Heated area, sq ft (depending on heating requirements) 450-1100
Nominal heat output, kW 2.3
Efficiency % LHV 87
Maximum load of wood per 24 hours, lbs 28.7
Heat release time at 100%, in hours (this is how long the heater stays at its hottest) 4.4
Heat release time at 50%, in hours (this how long the heater stays above 50% of its hottest) 17.5
Heat release time at 25%, in hours (this how long the heater stays above 25% of its hottest; aka T25) 26.2

Safety distances to combustibles
Safety distance, back, inches (can be reduced to 3" with a UL/ULC specified heat shield) 20
Safety distance, sides, inches (can be reduced to 3" with a UL/ULC specified heat shield) 14
Safety distance, top (inches) 10
Safety distance, front (inches) 48

Chimney connection and combustion air information
Recommended flue diameter, inches 7-8
