Kaarna M

News Material

Kaarna M

45 Classic

Heater power

4.5 kW

Sauna Room Volume, ft3

106-212 m3

News Material

Kaarna M

85 Classic

Heater power

8.5 kW

Sauna Room Volume, ft3

247-459 m3

News Material

Kaarna M

68 Classic

Heater power

6.8 kW

Sauna Room Volume, ft3

177–318 m3

News Material

Kaarna M

102 Classic

Heater power

10.2 kW

Sauna Room Volume, ft3

318–530 m3

News Material

Kaarna M

45 Nobile

Heater power

4.5 kW

Sauna Room Volume, ft3

106-212 m3

News Material

Kaarna M

85 Nobile

Heater power

8.5 kW

Sauna Room Volume, ft3

247-459 m3

News Material

Kaarna M

68 Nobile

Heater power

6.8 kW

Sauna Room Volume, ft3

177–318 m3

News Material

Kaarna M

102 Nobile

Heater power

10.2 kW

Sauna Room Volume, ft3

318–530 m3

Cladding

Sauna Room Volume, ft3

Technical specifications

Kaarna M 45 Classic

Sauna Room Volume, ft3: 106-212 m3

Product Number SS2191
Certification ETL

Dimensions
Heater Power, kW 4.5
Diameter, in 14
Adjustable Height, in 31-37
Net Weight (without Sauna Stones), lb 159
Maximum Stone Capacity, lb 66
Adjustable feet, in 0.8

Materials
Heater cladding
Frame

Safety distances to combustibles
Recommended Sauna Volume, Min., ft3 106
Recommended Sauna Volume, Max., ft3 212
Safety Distance to Side Wall, in 4
Safety Distance to Bench, in 1
Safety Distance to Ceiling, in 37
Safety distances to the floor, in 2

Heater control
Control type Tulikivi Sauna Control Panel

Electrical installation
IP Class IPX4
Electrical Group Options 240VAC, 1ph / 208VAC, 3ph
Supply Wire Size (AWG) 5 x AWG 16
Fuse Rating, A 20 A (240V, 1ph) / 15 A (208V, 3ph)

Kaarna M 85 Classic

Sauna Room Volume, ft3: 247-459 m3

Product Number SS2197
Certification ETL

Dimensions
Heater Power, kW 8.5
Diameter, in 14
Adjustable Height, in 31-37
Net Weight (without Sauna Stones), lb 159
Maximum Stone Capacity, lb 66
Adjustable feet, in 0.8

Materials
Heater cladding
Frame

Safety distances to combustibles
Recommended Sauna Volume, Min., ft3 247
Recommended Sauna Volume, Max., ft3 459
Safety Distance to Side Wall, in 4
Safety Distance to Bench, in 1 / 4*
Safety Distance to Ceiling, in 37

Heater control
Control type Tulikivi Sauna Control Panel

Electrical installation
IP Class IPX4
Electrical Group Options 240VAC, 1ph / 208VAC, 3ph
Supply Wire Size (AWG) 5 x AWG 14
Fuse Rating, A 40 A (240V, 1ph) / 25 A (208V, 3ph)

Kaarna M 68 Classic

Sauna Room Volume, ft3: 177–318 m3

Product Number SS2192
Certification ETL

Dimensions
Heater Power, kW 6.8
Diameter, in 14
Adjustable Height, in 31-37
Net Weight (without Sauna Stones), lb 159
Maximum Stone Capacity, lb 66
Adjustable feet, in 0.8

Materials
Heater cladding
Frame

Safety distances to combustibles
Recommended Sauna Volume, Min., ft3 177
Recommended Sauna Volume, Max., ft3 318
Safety Distance to Side Wall, in 4
Safety Distance to Bench, in 1 / 4*
Safety Distance to Ceiling, in 37

Heater control
Control type Tulikivi Sauna Control Panel

Electrical installation
IP Class IPX4
Electrical Group Options 240VAC, 1ph / 208VAC, 3ph
Supply Wire Size (AWG) 5 x AWG 16
Fuse Rating, A 30 A (240V, 1ph) / 20 A (208V, 3ph)

Kaarna M 102 Classic

Sauna Room Volume, ft3: 318–530 m3

Product Number SS2194
Certification ETL

Dimensions
Heater Power, kW 10.2
Diameter, in 14
Adjustable Height, in 31-37
Net Weight (without Sauna Stones), lb 159
Maximum Stone Capacity, lb 66
Adjustable feet, in 0.8

Materials
Heater cladding
Frame

Safety distances to combustibles
Recommended Sauna Volume, Min., ft3 9
Recommended Sauna Volume, Max., ft3 530
Safety Distance to Side Wall, in 4
Safety Distance to Bench, in 1 / 4*
Safety Distance to Ceiling, in 37

Heater control
Control type Tulikivi Sauna Control Panel

Electrical installation
IP Class IPX4
Electrical Group Options 240VAC, 1ph / 208VAC, 3ph
Supply Wire Size (AWG) 5 x AWG 14
Fuse Rating, A 45 A (240V, 1ph) / 30 A (208V, 3ph)

Kaarna M 45 Nobile

Sauna Room Volume, ft3: 106-212 m3

Product Number SS2195
Certification ETL

Dimensions
Heater Power, kW 4.5
Diameter, in 14
Adjustable Height, in 31-37
Net Weight (without Sauna Stones), lb 159
Maximum Stone Capacity, lb 66
Adjustable feet, in 0.8

Materials
Heater cladding
Frame

Safety distances to combustibles
Recommended Sauna Volume, Min., ft3 106
Recommended Sauna Volume, Max., ft3 212
Safety Distance to Side Wall, in 4
Safety Distance to Bench, in 1
Safety Distance to Ceiling, in 37

Heater control
Control type Tulikivi Sauna Control Panel

Electrical installation
IP Class IPX4
Electrical Group Options 240VAC, 1ph / 208VAC, 3ph
Supply Wire Size (AWG) 5 x AWG 16
Fuse Rating, A 20 A (240V, 1ph) / 15 A (208V, 3ph)

Kaarna M 85 Nobile

Sauna Room Volume, ft3: 247-459 m3

Product Number SS2197
Certification ETL

Dimensions
Heater Power, kW 8.5
Diameter, in 14
Adjustable Height, in 31-37
Net Weight (without Sauna Stones), lb 159
Maximum Stone Capacity, lb 66
Adjustable feet, in 0.8

Materials
Heater cladding
Frame

Safety distances to combustibles
Recommended Sauna Volume, Min., ft3 247
Recommended Sauna Volume, Max., ft3 459
Safety Distance to Side Wall, in 4
Safety Distance to Bench, in 1 / 4*
Safety Distance to Ceiling, in 37

Heater control
Control type Tulikivi Sauna Control Panel

Electrical installation
IP Class IPX4
Electrical Group Options 240VAC, 1ph / 208VAC, 3ph
Supply Wire Size (AWG) 5 x AWG 14
Fuse Rating, A 40 A (240V, 1ph) / 25 A (208V, 3ph)

Kaarna M 68 Nobile

Sauna Room Volume, ft3: 177–318 m3

Product Number SS2196
Certification ETL

Dimensions
Heater Power, kW 6.8
Diameter, in 14
Adjustable Height, in 31-37
Net Weight (without Sauna Stones), lb 159
Maximum Stone Capacity, lb 66
Adjustable feet, in 0.8

Materials
Heater cladding
Frame

Safety distances to combustibles
Recommended Sauna Volume, Min., ft3 177
Recommended Sauna Volume, Max., ft3 318
Safety Distance to Side Wall, in 4
Safety Distance to Bench, in 1 / 4*
Safety Distance to Ceiling, in 37

Heater control
Control type Tulikivi Sauna Control Panel

Electrical installation
IP Class IPX4
Electrical Group Options 240VAC, 1ph / 208VAC, 3ph
Supply Wire Size (AWG) 5 x AWG 16
Fuse Rating, A 30 A (240V, 1ph) / 20 A (208V, 3ph)

Kaarna M 102 Nobile

Sauna Room Volume, ft3: 318–530 m3

Product Number SS2198
Certification ETL

Dimensions
Heater Power, kW 10.2
Diameter, in 14
Adjustable Height, in 31-37
Net Weight (without Sauna Stones), lb 159
Maximum Stone Capacity, lb 66
Adjustable feet, in 0.8

Materials
Heater cladding
Frame

Safety distances to combustibles
Recommended Sauna Volume, Min., ft3 318
Recommended Sauna Volume, Max., ft3 530
Safety Distance to Side Wall, in 4
Safety Distance to Bench, in 1 / 4*
Safety Distance to Ceiling, in 37

Heater control
Control type Tulikivi Sauna Control Panel

Electrical installation
IP Class IPX4
Electrical Group Options 240VAC, 1ph / 208VAC, 3ph
Supply Wire Size (AWG) 5 x AWG 14
Fuse Rating, A 45 A (240V, 1ph) / 30 A (208V, 3ph)

Instructions & files

User manual Download
Cladding installation manual Download
Kiuasohjaimen käyttöohje Download
Kiuasohjaimen asennusohje Download
Kiuasohjaimen käyttöohje wifi Download
