Kaarna M

New Material

Kaarna M

68 Classic

The power of the Sauna heater

6,8 kW

Size sauna room

5-9 m3

New Material

Kaarna M

102 Classic

The power of the Sauna heater

10,2 kW

Size sauna room

9-15 m3

New Material

Kaarna M

45 Nobile

The power of the Sauna heater

4,5 kW

Size sauna room

3-6 m3

New Material

Kaarna M

85 Nobile

The power of the Sauna heater

8,5 kW

Size sauna room

7-13 m3

New Material

Kaarna M

68 Nobile

The power of the Sauna heater

6,8 kW

Size sauna room

5-9 m3

New Material

Kaarna M

102 Nobile

The power of the Sauna heater

10,2 kW

Size sauna room

9-15 m3

New Material

Kaarna M

45 Classic

The power of the Sauna heater

4,5 kW

Size sauna room

3-6 m3

New Material

Kaarna M

85 Classic

The power of the Sauna heater

8,5 kW

Size sauna room

7-13 m3

Cladding

Size sauna room

Technical specifications

Kaarna M 68 Classic

Size sauna room: 5-9 m3

Certificate ETL

Dimensions
Power, kW 6,8
Diameter, mm 370
Height, mm 790-940
Weight without stove stones, kg 72
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 5
Maximum sauna size, m3 9
Safety distances to the side wall, mm 100
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph/ 208VAC, 3ph
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 30 A (240V, 1ph) / 20 A (208V, 3ph)

Kaarna M 102 Classic

Size sauna room: 9-15 m3

Certificate ETL

Dimensions
Power, kW 10,2
Diameter, mm 370
Height, mm 790-940
Weight without stove stones, kg 72
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 9
Maximum sauna size, m3 15
Safety distances to the side wall, mm 100
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 45 A (240V, 1ph) / 30 A (208V, 3ph)

Kaarna M 45 Nobile

Size sauna room: 3-6 m3

Certificate ETL

Dimensions
Power, kW 4,5
Diameter, mm 370
Height, mm 790-940
Weight without stove stones, kg 72
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 3
Maximum sauna size, m3 6
Safety distances to the side wall, mm 100
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 20 A (240V, 1ph) / 15 A (208V, 3ph)

Kaarna M 85 Nobile

Size sauna room: 7-13 m3

Certificate ETL

Dimensions
Power, kW 8,5
Diameter, mm 370
Height, mm 790-940
Weight without stove stones, kg 72
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 7
Maximum sauna size, m3 13
Safety distances to the side wall, mm 100
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 40 A (240V, 1ph) / 25 A (208V, 3ph)

Kaarna M 68 Nobile

Size sauna room: 5-9 m3

Certificate ETL

Dimensions
Power, kW 6,8
Diameter, mm 370
Height, mm 790-940
Weight without stove stones, kg 72
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 5
Maximum sauna size, m3 9
Safety distances to the side wall, mm 100
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 30 A (240V, 1ph) / 20 A (208V, 3ph)

Kaarna M 102 Nobile

Size sauna room: 9-15 m3

Certificate ETL

Dimensions
Power, kW 10,2
Diameter, mm 370
Height, mm 790-940
Weight without stove stones, kg 72
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 9
Maximum sauna size, m3 15
Safety distances to the side wall, mm 100
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 45 A (240V, 1ph) / 30 A (208V, 3ph)

Kaarna M 45 Classic

Size sauna room: 3-6 m3

Certificate ETL

Dimensions
Power, kW 4,5
Diameter, mm 370
Height, mm 790-940
Weight without stove stones, kg 72
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 3
Maximum sauna size, m3 6
Safety distances to the side wall, mm 100
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 20 A (240V, 1ph) / 15 A (208V, 3ph)

Kaarna M 85 Classic

Size sauna room: 7-13 m3

Certificate ETL

Dimensions
Power, kW 8,5
Diameter, mm 370
Height, mm 790-940
Weight without stove stones, kg 72
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 7
Maximum sauna size, m3 13
Safety distances to the side wall, mm 100
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 40 A (240V, 1ph) / 25 A (208V, 3ph)

Instructions & files

Manual Download
Cladding installation manual Download
Sauna heaters controller user manual Download
Sauna heaters controller installation instructions Download
Sauna heaters controller user manual wifi Download
