Usva M

New Material

Usva M

45 Musta

The power of the Sauna heater

4,5 kW

Size sauna room

3-6 m3

New Material

Usva M

85 Musta

The power of the Sauna heater

8,5 kW

Size sauna room

7-13 m3

New Material

Usva M

68 Musta

The power of the Sauna heater

6,8 kW

Size sauna room

5-9 m3

New Material

Usva M

102 Musta

The power of the Sauna heater

10,2 kW

Size sauna room

9-15 m3

New Material

Usva M

45 Valkoinen

The power of the Sauna heater

4,5 kW

Size sauna room

3-6 m3

New Material

Usva M

85 Valkoinen

The power of the Sauna heater

8,5 kW

Size sauna room

7-13 m3

New Material

Usva M

68 Valkoinen

The power of the Sauna heater

6,8 kW

Size sauna room

5-9 m3

New Material

Usva M

102 Valkoinen

The power of the Sauna heater

10,2 kW

Size sauna room

9-15 m3

Cladding

Size sauna room

Technical specifications

Usva M 45 Musta

Size sauna room: 3-6 m3

Certificate ETL

Dimensions
Power, kW 4,5
Diameter, mm 360
Height, mm 790-940
Weight without stove stones, kg 26
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 3
Maximum sauna size, m3 6
Safety distances to the side wall, mm 50
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 20 A (240V, 1ph) / 15 A (208V, 3ph)

Usva M 85 Musta

Size sauna room: 7-13 m3

Certificate ETL

Dimensions
Power, kW 8,5
Diameter, mm 360
Height, mm 790-940
Weight without stove stones, kg 26
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 7
Maximum sauna size, m3 13
Safety distances to the side wall, mm 50
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 40 A (240V, 1ph) / 25 A (208V, 3ph)

Usva M 68 Musta

Size sauna room: 5-9 m3

Certificate ETL

Dimensions
Power, kW 6,8
Diameter, mm 360
Height, mm 790-940
Weight without stove stones, kg 26
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 5
Maximum sauna size, m3 9
Safety distances to the side wall, mm 50
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 30 A (240V, 1ph) / 20 A (208V, 3ph)

Usva M 102 Musta

Size sauna room: 9-15 m3

Certificate ETL

Dimensions
Power, kW 10,2
Diameter, mm 360
Height, mm 790-940
Weight without stove stones, kg 26
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 9
Maximum sauna size, m3 15
Safety distances to the side wall, mm 50
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 45 A (240V, 1ph) / 30 A (208V, 3ph)

Usva M 45 Valkoinen

Size sauna room: 3-6 m3

Certificate ETL

Dimensions
Power, kW 4,5
Diameter, mm 360
Height, mm 790-940
Weight without stove stones, kg 26
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 3
Maximum sauna size, m3 6
Safety distances to the side wall, mm 50
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 20 A (240V, 1ph) / 15 A (208V, 3ph)

Usva M 85 Valkoinen

Size sauna room: 7-13 m3

Certificate ETL

Dimensions
Power, kW 8,5
Diameter, mm 360
Height, mm 790-940
Weight without stove stones, kg 26
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 7
Maximum sauna size, m3 13
Safety distances to the side wall, mm 50
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 40 A (240V, 1ph) / 25 A (208V, 3ph)

Usva M 68 Valkoinen

Size sauna room: 5-9 m3

Certificate ETL

Dimensions
Power, kW 6,8
Diameter, mm 360
Height, mm 790-940
Weight without stove stones, kg 26
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 5
Maximum sauna size, m3 9
Safety distances to the side wall, mm 50
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 16
Fuses, pcs x ampere (A) 30 A (240V, 1ph) / 20 A (208V, 3ph)

Usva M 102 Valkoinen

Size sauna room: 9-15 m3

Certificate ETL

Dimensions
Power, kW 10,2
Diameter, mm 360
Height, mm 790-940
Weight without stove stones, kg 26
Sauna stones kg max. 30
Sauna heaters adjustment legs, mm 20

Materials
Surface of sauna heaters
Frame

Safety distances
Minimum sauna size, m3 9
Maximum sauna size, m3 15
Safety distances to the side wall, mm 50
Safety distances to the footboard in front, mm 20
Safety distances to the ceiling, mm 950
Safety distances to the floor, mm 50

Sauna heater control
Control panel Tulikivi Sauna Control Panel

Electrical installation
Security rating IPX4
Three-phase operating voltage 240VAC, 1ph / 208VAC, 3ph
Supply cable, mm2 5 x AWG 14
Fuses, pcs x ampere (A) 45 A (240V, 1ph) / 30 A (208V, 3ph)

Instructions & files

Manual Download
Cladding installation manual Download
Sauna heaters controller user manual Download
Sauna heaters controller installation instructions Download
Sauna heaters controller user manual wifi Download
